产品: TLR4 抗体
货号: AF7017
描述: Rabbit polyclonal antibody to TLR4
应用: WB IHC IF/ICC
反应: Human, Mouse, Rat
分子量: 100~130kDa; 96kD(Calculated).
蛋白号: O00206
RRID: AB_2835322

浏览相似产品>>

   规格 价格 库存
 50ul RMB¥ 1250 现货
 100ul RMB¥ 2300 现货
 200ul RMB¥ 3000 现货

货期: 当天发货

联系销售

产品描述

来源:
Rabbit
应用:
WB 1:500-1:2000, IHC 1:50-1:200, IF/ICC 1:100-1:500
*The optimal dilutions should be determined by the end user.
*Tips:

WB: 适用于变性蛋白样本的免疫印迹检测. IHC: 适用于组织样本的石蜡(IHC-p)或冰冻(IHC-f)切片样本的免疫组化/荧光检测. IF/ICC: 适用于细胞样本的荧光检测. ELISA(peptide): 适用于抗原肽的ELISA检测.

反应:
Human,Mouse,Rat
克隆:
Polyclonal
特异性:
TLR4 Antibody detects endogenous levels of total TLR4.
RRID:
AB_2835322
引用格式: Affinity Biosciences Cat# AF7017, RRID:AB_2835322.
偶联:
Unconjugated.
纯化:
The antiserum was purified by peptide affinity chromatography using SulfoLink™ Coupling Resin (Thermo Fisher Scientific).
保存:
Rabbit IgG in phosphate buffered saline , pH 7.4, 150mM NaCl, 0.02% sodium azide and 50% glycerol. Store at -20 °C. Stable for 12 months from date of receipt.
别名:

展开/折叠

ARMD10; CD284; CD284 antigen; Homolog of Drosophila toll; hToll; TLR 4; TLR4; TLR4_HUMAN; TOLL; Toll like receptor 4; Toll-like receptor 4;

抗原和靶标

免疫原:
Uniprot:
基因/基因ID:
表达:
O00206 TLR4_HUMAN:

Highly expressed in placenta, spleen and peripheral blood leukocytes (PubMed:9435236, PubMed:9237759). Detected in monocytes, macrophages, dendritic cells and several types of T-cells (PubMed:9237759, PubMed:27022195).

描述:
Toll like receptors (TLR) are highly conserved throughout evolution and have been implicated in the innate defense to many pathogens. In Drosophila toll is required for the anti fungal response, while the related 18 wheeler is involved in antibacterial defenses. In mammals, TLR identified as type I transmembrane signaling receptors with pattern recognition capabilities have been implicated in the innate host defense to pathogens. TLR4 has been identified next to MD2 and CD14 as a receptor that is central to the innate immune response to lipopolysaccharides (LPS) of Gram negative bacteria.
序列:
MMSASRLAGTLIPAMAFLSCVRPESWEPCVEVVPNITYQCMELNFYKIPDNLPFSTKNLDLSFNPLRHLGSYSFFSFPELQVLDLSRCEIQTIEDGAYQSLSHLSTLILTGNPIQSLALGAFSGLSSLQKLVAVETNLASLENFPIGHLKTLKELNVAHNLIQSFKLPEYFSNLTNLEHLDLSSNKIQSIYCTDLRVLHQMPLLNLSLDLSLNPMNFIQPGAFKEIRLHKLTLRNNFDSLNVMKTCIQGLAGLEVHRLVLGEFRNEGNLEKFDKSALEGLCNLTIEEFRLAYLDYYLDDIIDLFNCLTNVSSFSLVSVTIERVKDFSYNFGWQHLELVNCKFGQFPTLKLKSLKRLTFTSNKGGNAFSEVDLPSLEFLDLSRNGLSFKGCCSQSDFGTTSLKYLDLSFNGVITMSSNFLGLEQLEHLDFQHSNLKQMSEFSVFLSLRNLIYLDISHTHTRVAFNGIFNGLSSLEVLKMAGNSFQENFLPDIFTELRNLTFLDLSQCQLEQLSPTAFNSLSSLQVLNMSHNNFFSLDTFPYKCLNSLQVLDYSLNHIMTSKKQELQHFPSSLAFLNLTQNDFACTCEHQSFLQWIKDQRQLLVEVERMECATPSDKQGMPVLSLNITCQMNKTIIGVSVLSVLVVSVVAVLVYKFYFHLMLLAGCIKYGRGENIYDAFVIYSSQDEDWVRNELVKNLEEGVPPFQLCLHYRDFIPGVAIAANIIHEGFHKSRKVIVVVSQHFIQSRWCIFEYEIAQTWQFLSSRAGIIFIVLQKVEKTLLRQQVELYRLLSRNTYLEWEDSVLGRHIFWRRLRKALLDGKSWNPEGTVGTGCNWQEATSI

翻译修饰 - O00206 作为底物

Site PTM Type Enzyme
N35 N-Glycosylation
N173 N-Glycosylation
T175 Phosphorylation
N205 N-Glycosylation
N282 N-Glycosylation
N309 N-Glycosylation
N497 N-Glycosylation
N526 N-Glycosylation
Y551 Phosphorylation
N575 N-Glycosylation
N624 N-Glycosylation
Y674 Phosphorylation
Y680 Phosphorylation
S730 Phosphorylation
S738 Phosphorylation
S790 Phosphorylation Q15139 (PRKD1)
S800 Phosphorylation

研究背景

功能:

Cooperates with LY96 and CD14 to mediate the innate immune response to bacterial lipopolysaccharide (LPS). Acts via MYD88, TIRAP and TRAF6, leading to NF-kappa-B activation, cytokine secretion and the inflammatory response. Also involved in LPS-independent inflammatory responses triggered by free fatty acids, such as palmitate, and Ni(2+). Responses triggered by Ni(2+) require non-conserved histidines and are, therefore, species-specific. Both M.tuberculosis HSP70 (dnaK) and HSP65 (groEL-2) act via this protein to stimulate NF-kappa-B expression. In complex with TLR6, promotes sterile inflammation in monocytes/macrophages in response to oxidized low-density lipoprotein (oxLDL) or amyloid-beta 42. In this context, the initial signal is provided by oxLDL- or amyloid-beta 42-binding to CD36. This event induces the formation of a heterodimer of TLR4 and TLR6, which is rapidly internalized and triggers inflammatory response, leading to the NF-kappa-B-dependent production of CXCL1, CXCL2 and CCL9 cytokines, via MYD88 signaling pathway, and CCL5 cytokine, via TICAM1 signaling pathway, as well as IL1B secretion. Binds electronegative LDL (LDL(-)) and mediates the cytokine release induced by LDL(-). Stimulation of monocytes in vitro with M.tuberculosis PstS1 induces p38 MAPK and ERK1/2 activation primarily via TLR2, but also partially via this receptor.

翻译修饰:

N-glycosylated. Glycosylation of Asn-526 and Asn-575 seems to be necessary for the expression of TLR4 on the cell surface and the LPS-response. Likewise, mutants lacking two or more of the other N-glycosylation sites were deficient in interaction with LPS.

Phosphorylated on tyrosine residues by LYN after binding lipopolysaccharide.

细胞定位:

Cell membrane>Single-pass type I membrane protein. Early endosome. Cell projection>Ruffle.
Note: Upon complex formation with CD36 and TLR6, internalized through dynamin-dependent endocytosis (PubMed:20037584). Colocalizes with RFTN1 at cell membrane and then together with RFTN1 moves to endosomes, upon lipopolysaccharide stimulation.

Extracellular region or secreted Cytosol Plasma membrane Cytoskeleton Lysosome Endosome Peroxisome ER Golgi apparatus Nucleus Mitochondrion Manual annotation Automatic computational assertionSubcellular location
组织特异性:

Highly expressed in placenta, spleen and peripheral blood leukocytes. Detected in monocytes, macrophages, dendritic cells and several types of T-cells.

亚基结构:

Belongs to the lipopolysaccharide (LPS) receptor, a multi-protein complex containing at least CD14, LY96 and TLR4. Binding to bacterial LPS leads to homodimerization. Interacts with LY96 via the extracellular domain. Interacts with MYD88 and TIRAP via their respective TIR domains (By similarity). Interacts with TICAM2. Interacts with NOX4. Interacts with CNPY3 (By similarity). Interacts with HSP90B1. The interaction with both CNPY3 and HSP90B1 is required for proper folding in the endoplasmic reticulum. Interacts with MAP3K21; this interaction leads to negative regulation of TLR4 signaling. Interacts with CD36, following CD36 stimulation by oxLDL or amyloid-beta 42, and forms a heterodimer with TLR6. The trimeric complex is internalized and triggers inflammatory response. LYN kinase activity facilitates TLR4-TLR6 heterodimerization and signal initiation. Interacts with TICAM1 in response to LPS in a WDFY1-dependent manner. Interacts with WDFY1 in response to LPS (By similarity). Interacts with SMPDL3B (By similarity). Interacts with CEACAM1; upon lipopolysaccharide stimulation, forms a complex including TLR4 and the phosphorylated form of SYK and CEACAM1, which in turn, recruits PTPN6 that dephosphorylates SYK, reducing the production of reactive oxygen species (ROS) and lysosome disruption, which in turn, reduces the activity of the inflammasome (By similarity). Interacts with RFTN1; the interaction occurs in response to lipopolysaccharide stimulation. Interacts with SCIMP; the interaction occurs in response to lipopolysaccharide stimulation and is enhanced by phosphorylation of SCIMP by LYN (By similarity). This interaction facilitates the phosphorylation of TLR4 by LYN which elicits a selective cytokine response in macrophages (By similarity).

(Microbial infection) In case of infection, interacts with uropathogenic E.coli protein TcpC.

蛋白家族:

The TIR domain mediates interaction with NOX4.

The TIR domain mediates NAD(+) hydrolase (NADase) activity. Self-association of TIR domains is required for NADase activity.

Belongs to the Toll-like receptor family.

研究领域

· Cellular Processes > Transport and catabolism > Phagosome.   (View pathway)

· Cellular Processes > Cell growth and death > Necroptosis.   (View pathway)

· Environmental Information Processing > Signal transduction > NF-kappa B signaling pathway.   (View pathway)

· Environmental Information Processing > Signal transduction > HIF-1 signaling pathway.   (View pathway)

· Environmental Information Processing > Signal transduction > PI3K-Akt signaling pathway.   (View pathway)

· Human Diseases > Infectious diseases: Bacterial > Pathogenic Escherichia coli infection.

· Human Diseases > Infectious diseases: Bacterial > Salmonella infection.

· Human Diseases > Infectious diseases: Bacterial > Pertussis.

· Human Diseases > Infectious diseases: Bacterial > Legionellosis.

· Human Diseases > Infectious diseases: Parasitic > Leishmaniasis.

· Human Diseases > Infectious diseases: Parasitic > Chagas disease (American trypanosomiasis).

· Human Diseases > Infectious diseases: Parasitic > Malaria.

· Human Diseases > Infectious diseases: Parasitic > Toxoplasmosis.

· Human Diseases > Infectious diseases: Parasitic > Amoebiasis.

· Human Diseases > Infectious diseases: Bacterial > Tuberculosis.

· Human Diseases > Infectious diseases: Viral > Hepatitis B.

· Human Diseases > Infectious diseases: Viral > Measles.

· Human Diseases > Infectious diseases: Viral > Influenza A.

· Human Diseases > Cancers: Overview > Proteoglycans in cancer.

· Human Diseases > Immune diseases > Inflammatory bowel disease (IBD).

· Human Diseases > Immune diseases > Rheumatoid arthritis.

· Organismal Systems > Immune system > Toll-like receptor signaling pathway.   (View pathway)

· Organismal Systems > Immune system > NOD-like receptor signaling pathway.   (View pathway)

文献引用

1). Anti-inflammatory effect of piperine ameliorates insulin resistance in monosodium glutamate–treated obese mice. METABOLISM-CLINICAL AND EXPERIMENTAL (PubMed: 19800637) [IF=9.8]

Application: WB    Species: Mouse    Sample: RAW264.7 cells

Figure 9. Effects of piperine on LPS-induced M1-like polarization in RAW264.7 cells. RAW264.7 cells were pretreated with piperine at 20-80 μM for 12 h and then stimulated by LPS (1 μg/ml) for 24 h. (a-c) The mRNA levels of CD11c, IL-1β and TNF-α were analyzed by qPCR. (d) The IL-1β level in cell supernatant was measured by ELISA. (e-f) The protein levels of TLR-4, CD11c and IL-1β were tested by Western Blotting. Data are expressed as mean±SD, n=3. ####p

2). Oxyberberine, a novel gut microbiota-mediated metabolite of berberine, possesses superior anti-colitis effect: impact on intestinal epithelial barrier, gut microbiota profile and TLR4-MyD88-NF-κB pathway. PHARMACOLOGICAL RESEARCH (PubMed: 31863867) [IF=9.3]

Application: WB    Species: Mice    Sample: colonic tissues

Fig. 6. Effect of OBB on the activation of TLR4-MyD88-NF-κB signaling pathway in DSS-induced colonic tissues. (A) Representative Western blotting images of TLR4, MyD88, cytoplasmic p65, nuclear p65, p-IκBα and IκBα. Changes in the relative protein expression levels of TLR4 (B), MyD88 (C), nuclear p65 (D), cytoplasmic p65 (E), and p-IκBα/IκBα ratio (F) were measured. Data are shown as the mean ± SEM (n = 3). # P < 0.05, ## P < 0.01 vs. Control group, * P < 0.05, ** P < 0.01 vs. DSS group.

3). Baicalin ameliorates neuroinflammation-induced depressive-like behavior through inhibition of toll-like receptor 4 expression via the PI3K/AKT/FoxO1 pathway. Journal of Neuroinflammation (PubMed: 31068207) [IF=9.3]

Application: WB    Species: mouse    Sample: hippocampus

Fig. 3| The role of TLR4 in alleviating neuroinflammation of baicalin. Prophylactic treatment of TAK-242 or baicalin inhibited LPS-induced neuroinflammation as well as depressive-like behaviors. d The levels of TLR4 and p-FoxO1 in the hippocampus were measured by western blotting and were quantified and normalized with their respective β-actin or total FoxO1 levels (n = 4). Data were normalized to the control and presented as means ± SEM. #p < 0.05, ##p < 0.01, ###p < 0.005 vs. control; *p < 0.05, **p < 0.01, ***p < 0.005 vs. LPS. TAK, TAK-242

Application: IF/ICC    Species: mouse    Sample: BV2 cells

Fig. 7 |Baicalin regulates LPS-induced TLR4 expression by activating the PI3K/AKT/FoxO1 pathway in BV2 cells.e BV2 cells were stained with a TLR4 antibody and observed with fluorescence microscopy. Green, TLR4; blue: DAPI; scale bar, 50 μm

4). Extracellular vesicles derived from mesenchymal stem cells alleviate neuroinflammation and mechanical allodynia in interstitial cystitis rats by inhibiting NLRP3 inflammasome activation. Journal of Neuroinflammation (PubMed: 35387668) [IF=9.3]

Application: WB    Species: rat    Sample: spinal dorsal horn

Fig. 8 | MSC-EVs inhibit activity of TLR4/NF-κB signal pathway in SDH of IC rats. A–C Western blot analysis showing that expression level of TLR4 and phosphorylation ratio of NF‐κB (p65) were signifcantly increased in SDH of IC rats compared with normal rats, and intrathecal injection of MSC-EVs signifcantly decreased expression level of TLR4 and phosphorylation ratio of NF‐κB (p65) in SDH of IC rats

5). Arsenic trioxide ameliorates experimental autoimmune encephalomyelitis in C57BL/6 mice by inducing CD4+ T cell apoptosis. Journal of Neuroinflammation (PubMed: 32375831) [IF=9.3]

6). Berberine-mediated up-regulation of surfactant protein D facilitates cartilage repair by modulating immune responses via the inhibition of TLR4/NF-ĸB signaling. Pharmacological Research (PubMed: 32057894) [IF=9.3]

Application: WB    Species: rat    Sample: knee joints

Fig. 5. Chondrocyte apoptosis and immune molecular biomarkers were inhibited by BBR binding to SP-D in vivo in OA. OA model rats (n = 5/group) were injected using 25 μl of 200 μM BBR, followed by 25 μl rhSP-D (40 μg/mL) 1 day later. Sham-operated and OA-induction groups received an injection of 50 μl PBS into the right knee joint. For rats receiving rAAV-GFP or rAAV-SP-D shRNA, injections were performed for 10 consecutive days beginning 1 day after the initial BBR injection. At 10 weeks post-surgery, animals were sacrificed and the knee joints were collected for TUNEL and IHC analysis. (A) TUNEL staining (400 ×) was used to assess apoptosis. The p-p65, TLR4, F4/80, CD68, and CD34 expression was assessed via IHC (400 × with higher 800 × magnification inset). (B) Quantification of the indicated proteins in IHC images. Each column represents the mean ± SEM (n = 5). ***P < 0.001 versus the sham-operated group; ##P < 0.01 and ###P < 0.001 versus the OA-induction group; &P < 0.05 and &&P < 0.01 versus the OA + BBR group.

7). Commensal cow Roseburia reduces gut-dysbiosis-induced mastitis through inhibiting bacterial translocation by producing butyrate in mice. Cell Reports (PubMed: 36417859) [IF=8.8]

8). Dental pulp stem cell‐derived exosomes alleviate cerebral ischaemia‐reperfusion injury through suppressing inflammatory response. CELL PROLIFERATION (PubMed: 34231932) [IF=8.5]

Application: WB    Species: Mice    Sample:

FIGURE 3 Effect of DPSC‐Exos on the expression of TLR4, MyD88, NF‐κB p65 and HMGB1 on day 7 after cerebral I/R damage. (A) The relative expression level of TLR4. (B) The relative expression level of MyD88. (C) The relative expression level of NF‐κB p65. (D) The relative expression level of nuclear HMGB1. (E) The relative expression level of cytoplasmic HMGB1. Protein samples were acquired from the ischaemic cortex and assayed by western blot. Nuclear proteins were normalized to the intensity of Histone H3, and cytoplasmic and total proteins were normalized to the intensity of GAPDH or β‐actin. Data were expressed as means ± SD (n = 3). ## P < .01 versus the sham group; *P < .05 and **P < .01 versus the I/R + PBS group. DPSC‐Exos, dental pulp stem cell‐derived exosomes; HMGB1, high‐mobility group box 1 protein; I/R, ischaemia/reperfusion; MyD88, myeloid differentiation protein 88; NF‐κB, nuclear factor‐kappa B; PBS, phosphate‐buffered saline; TLR4, toll‐like receptor‐4

9). Sodium alginate and galactooligosaccharides ameliorate metabolic disorders and alter the composition of the gut microbiota in mice with high-fat diet-induced obesity. International Journal of Biological Macromolecules (PubMed: 35718141) [IF=8.2]

10). Network pharmacology based research into the effect and potential mechanism of Portulaca oleracea L. polysaccharide against ulcerative colitis. Computers in Biology and Medicine (PubMed: 37216777) [IF=7.7]

加载更多

限制条款

产品的规格、报价、验证数据请以官网为准,官网链接:www.affbiotech.com | www.affbiotech.cn(简体中文)| www.affbiotech.jp(日本語)

产品的数据信息为Affinity所有,未经授权不得收集Affinity官网数据或资料用于商业用途,对抄袭产品数据的行为我们将保留诉诸法律的权利。

产品相关数据会因产品批次、产品检测情况随时调整,如您已订购该产品,请以订购时随货说明书为准,否则请以官网内容为准,官网内容有改动时恕不另行通知。

Affinity保证所销售产品均经过严格质量检测。如您购买的商品在规定时间内出现问题需要售后时,请您在Affinity官方渠道提交售后申请。

产品仅供科学研究使用。不用于诊断和治疗。

产品未经授权不得转售。

Affinity Biosciences将不会对在使用我们的产品时可能发生的专利侵权或其他侵权行为负责。Affinity Biosciences, Affinity Biosciences标志和所有其他商标所有权归Affinity Biosciences LTD.
